EN545 Ductile Iron Pipe Fittings are made from high quality materials and designed to provide superior performance in a wide range of applications. These fittings are designed to meet EN545 standards and are used in a variety of fields, including water supply and distribution, sewage treatment, industrial and chemical processing, and more...
Material: iron GGG500-7, GGG450-10 or Ductile iron
Standard: ISO2531, EN545, AWWA153 & C110
Size: DN60mm-2000mm
Hardness: maximum≤250HB
Tensile Strength: minimum≥420MPA
Elongation: minimum≥5%
Certificate: ISO 9001 2008 and BV Product Conformity
Socket joint : T type ( push-on type) / K type ( MJ type)
Gasket: are SBR, EPDM, NBR
Coating: Cement lining inside, zinc primer and bitumen painting outside; fusion bonded epoxy coating; bitumen painting inside and outside red anti-rust coating.
Packing: wooden cases with plastic layer, wooden pallets with plastic layer
| Material: | Ductile Cast Iron |
| Standard: | EN545 |
| Pressure: | PN10, PN16, PN25 |
| Flange drilled: | ISO7005-2, BS4504, EN1092-2, DIN2501 |
| Specification: | DN80 to DN2600 |
| Joints type: | Typon joint (push on joint) |
| Application: | Water supply project, drainage, sewerage, Irrigation, water pipeline |
| Surface Inside: | Portland Cement mortar lining, bitumen paint, epoxy paint, powder |
| Surface Outside: | Epoxy paint, bitumen paint, epoxy powder coating |
| Accessories: | Gaskets, bolts and nuts available upon request |
| Inspection: | SGS, BV, third party inspection |
| Sample: | Sample for free, but you should pay for the freight charge for the samples |
| Payment: | 30% TT upon placing order and 70% TT when the goods are finished but before shipment. |
| Packing methods: | Wooden case/pallet with plastic layer, or as per customer's requirements |
EN545 Ductile Iron Pipe Fittings are made from high quality materials and designed to provide superior performance in a wide range of applications. These fittings are designed to meet EN545 standards and are used in a variety of fields, including water supply and distribution, sewage treatment, industrial and chemical processing, and more.
Ductile Iron Pipe Fittings are made from ductile iron, which is a type of iron that is much stronger and more durable than traditional cast iron. This makes these fittings ideal for use in heavy-duty applications, where strength and durability are key factors.
EN545 Ductile Iron Pipe Fittings are available in a wide range of sizes, and can be customized to meet the specific needs of your application. They are designed to be easy to install, and can be used with a variety of pipe materials, including PVC, HDPE, and others.
EN545 Ductile Iron Pipe Fittings are highly resistant to corrosion and wear, and are designed to provide long-lasting, trouble-free performance. They are also highly versatile, and can be used in a wide range of configurations and applications.
If you are looking for high-quality, reliable pipe fittings for your application, EN545 Ductile Iron Pipe Fittings are an excellent choice. With their superior performance, durability, and versatility, these fittings offer exceptional value and performance in a wide range of applications.
