Ductile iron elbow is a vital component in the piping system that provides a convenient way of directing the flow of fluids and gases. It is made of ductile iron, also known as nodular cast iron, which is known for its high strength, exceptional corrosion resistance, and long-lasting durability...
Material: iron GGG500-7, GGG450-10 or Ductile iron
Standard: ISO2531,EN545, AWWA153 & C110
Size: DN60mm-2000mm
Certificate: ISO 9001 2008 and BV Product Conformity
Gasket: are SBR, EPDM, NBR
Coating: Cement lining inside, zinc primer and bitumen painting outside; fusion bonded epoxy coating; bitumen painting inside and outside red anti-rust coating.
Packing: wooden cases with plastic layer ,wooden pallets with plastic layer
| Material | Ductile iron |
| Standard | EN545, EN598, ISO2531, ANSI/AWWA, etc |
| Size | DN50-DN2600mm |
| Color | Blue, Black, Red Ect. |
| Joint Type | T type (push on joint), K- type, Flange type, Self-restrained type |
| Pressure | PN10/PN16/PN25/PN40 |
| Brand | MIDAS |
| OEM | Acceptable |
| Fitting Types | Socket bend, Flanged bend, Socket and Flanged Tee, Flanged socket, Socket taper, blank flanges, as well as Flanged adaptor, coupling, dismantling joints, Fitting for PVC pipes and Other pipeline accessories |
| Surface treatment | Fusion bonded epoxy coating |
| cement lining inside and zinc and bitumen coating outside | |
| Zinc+bitumen inside and outside | |
| According to customers' requirements | |
| Inspection | Foundry in-house: Third party inspection available upon request |
| Application | Stormwater systems Wastewater systems Irrigation systems |
| Advantage | We can make various high quality ductile iron fittings according to customer's requests. |
| Package | Standard wooden pallets or wooden cases |
Ductile iron elbow is a vital component in the piping system that provides a convenient way of directing the flow of fluids and gases. It is made of ductile iron, also known as nodular cast iron, which is known for its high strength, exceptional corrosion resistance, and long-lasting durability. These qualities make it an ideal material for applications in challenging environments such as oil and gas, chemical processing, and wastewater treatment plants.
The ductile iron elbow is designed to connect two pipes at an angle, helping to change the direction of fluid flow. It can be used in both above-ground and underground piping systems and is compatible with a wide range of fluids ranging from potable water to highly corrosive chemicals and gases.
Our range of ductile iron elbows is available in various angles, sizes, and wall thicknesses, ensuring that there is a perfect fit for every application. We offer 90-degree, 45-degree, and 22.5-degree elbows in sizes ranging from 50mm to 1200mm and wall thicknesses ranging from 3mm to 20mm.
The manufacturing of our ductile iron elbows is carried out with strict adherence to international standards such as ASTM, BS, ISO, EN, and AS/NZS. The product undergoes rigorous testing to ensure its quality and durability before being packaged and delivered to customers.
Our ductile iron elbows provide excellent resistance against corrosion, impact, and high pressures, making them ideal for use in challenging environments. They provide a reliable and cost-effective solution for all your piping needs. We offer strict quality control, competitive pricing, timely delivery, and excellent customer service. Contact us today to learn more about our ductile iron elbows and how they can benefit your application.
