The actuated butterfly valve is a highly efficient and reliable valve that is designed to control the flow of liquids and gases in various industrial applications. The valve features a disc that rotates around a central axis to regulate the flow of materials through the pipe...
The actuated butterfly valve is a highly efficient and reliable valve that is designed to control the flow of liquids and gases in various industrial applications. The valve features a disc that rotates around a central axis to regulate the flow of materials through the pipe. Behind the high-speed operation of modern industry, the precision and efficiency of fluid control technology are crucial. Actuated butterfly valve, as a core equipment in the field of fluid control, has become a key guarantee for the stable operation of various pipeline systems due to its excellent automation performance and flexible regulation ability.
It uses the valve stem to drive the disc-shaped valve disc to rotate 90 ° inside the valve body, achieving the opening, closing, and flow regulation of the fluid in the pipeline. Unlike traditional manual butterfly valves, actuated butterfly valves rely on external power sources such as electric, pneumatic, and hydraulic, greatly improving the automation and response speed of operation.
Actuated butterfly valves have significant advantages: they are compact in structure, small in size, and require only one-third of the installation space of gate valves; The opening resistance is small, and the fluid resistance coefficient is about 80% lower than that of the shut-off valve, which can effectively reduce energy consumption. At the same time, multiple driving modes combined with intelligent control systems can achieve precise flow regulation and automated monitoring.
In water supply and drainage engineering, it is used to regulate the water flow of urban water supply systems. In the field of gas transmission, the quick cut-off function ensures pipeline safety. In the sewage treatment system of the environmental protection industry, stable control of media such as mud and sewage can be achieved.
With the acceleration of industrial intelligence, actuated butterfly valve, with their high efficiency, flexibility, and reliability, are continuously innovating the application boundaries of fluid control technology, injecting strong power into the efficient operation and green development of multiple fields such as energy, chemical, and environmental protection, and becoming a key equipment for modern industrial fluid management.
No | PART NAME | MATERIAL | ||
1 | Body | Cast Iron, Ductile Iron, Carbon Steel, Stainless Steel | ||
2 | Seat | NBR,EPDM, Viton,Neoprene,HYPALON,Silicon | ||
3 | Shaft | Stainless Steel416,carbon steel/tianium steel/ SS316/SS304/monel | ||
4 | Disc | Ductile Iron+Ni,CF8,CF8M,Bronze | ||
5 | Pin | Stainless Steel | ||
6 | Bushing | PTFE,Bronze | ||
7 | O-Ring | NBR,EPDM | ||
Product Dimensions
| Size | DN40-DN1200 |
| Body material | Cast Iron/Ductile Iron |
| Working pressure | PN1.0/1.6Mpa(150/200PSI) |
| Design standard | EN593/ ISO5752 /BS5155/AWWA C504 |
| Type | Double Flange Eccentric, Double Flange Concentric, Water type , Lug type , U type,Grooved type |
| Suitable Media | Water, sewage, oil, food, gas and so on |
| Coating | 250 Microns Fusion Bonded Epoxy Coating or customers request. |
| Operator | Handle Lever, Worm Gear, Electrical Actuator, Pneumatic Actuator |
